1T15M-6 | Firestone Imperial Air Spring

Name: 1T15M-6 | Firestone Imperial Air Spring
Brand: Firestone
SKU: 150996686
Rating: 5.0 (83 reviews)

Firestone Imperial Air Spring 1T15M-6

Style: 1T15M-6 (Two Ply Bellows):	Blind nuts, 1/4 NPT air inlet Blind nuts, 1/4 NPT air inlet, bumper Blind nuts, 3/4 NPT air inlet Blind nuts, 3/4 NPT air inlet, bumper Blind nuts, 3/4 NPT air inlet (piston not included)
SKU:
Availability:

Quantity:



Inquire Add to Basket

Details

Brand

Firestone

Article Status

Normal

Bellows Style

1T15M-6

1T15M 6

1T15M6

New Bellows Style

1T15M SERIES C01-358-2149

1T15M SERIES C01 358 2149

1T15M SERIES C013582149

HS Code

8708809000

Material of Top Plate

Steel

Material of Piston

Composite

Air Inlet

1/4 NPT or 3/4 NPT

Medium

Compressed air

Place of Origin

USA

Application

Trailer/Axle

Industrial equipment

Assembly Weight (bead plate version, no bumper)

13.0 lbs

5.90 kg

Dynamic Characteristics

Dynamic Characteristics at Design Height (Required for Airmount™ isolator design only)
Volume @ 100 PSIG = 987 in3			Natural Frequency
Gauge Pressure (PSIG)	Load (lbs.)	Spring Rate (lbs./in.)	Natural Frequency
Gauge Pressure (PSIG)	Load (lbs.)	Spring Rate (lbs./in.)	f (CPM)	f (Hz)
40	2730	395	71	1.19
60	4130	541	68	1.13
80	5590	707	67	1.12
100	7030	852	65	1.09
Recommended Airmount™ Isolator Design Height: 14.0 in.

Force Table

Force Table (Use for Airstroke™ actuator design)
Assembly Height (in.)	Volume @ 100 PSIG (in3)	Force (lbs.)
Assembly Height (in.)	Volume @ 100 PSIG (in3)	@ 20 PSIG	@ 40 PSIG	@ 60 PSIG	@ 80 PSIG	@ 100 PSIG
18.0	1274	1100	2220	3420	4670	5980
16.0	1134	1290	2640	4000	5410	6840
14.0	987	1330	2730	4130	5590	7030
12.0	941	1330	2710	4170	5590	7010
10.0	693	1380	2790	4270	5730	7240
8.0	533	1500	3060	4670	6280	7950
