90220 | 165 PSI On, 200 PSI Off, 1/8" NPT, 16 GA wires (20-AMP)

Name: 90220 | 165 PSI On, 200 PSI Off, 1/8" NPT, 16 GA wires (20-AMP)
Brand: Viair
Rating: 5.0 (18 reviews)

165 PSI On, 200 PSI Off, 1/8" NPT, 16 GA wires (20-AMP)

Model:
90220
Brand:
Viair

SKU:
Availability:

Quantity:



Inquire Add to Basket

Viair Pressure Switch Sealed Pressure Switch 1/8″ NPT Pressure Switch 20A Pressure Switch

Details

Brand

Viair

Part number

90220

Switch on condition

Pressure ≤ 165 psi (± 5%)

Pressure ≤ 11.40 bar (± 5%)

Switch off condition

Pressure ≥ 200 psi (± 5%)

Pressure ≥ 13.79 bar (± 5%)

Operation current

max. 20-amp

Port fitting

1/8” NPT (Male thread)

Diameter of wires

16 gauges

1.65 mm

Country of origin

USA

Applications

Pneumatic equipment

Assembly weight

0.11 lbs

0.05 kg

Product Description

Viair's sealed pressure switches are designed to protect from elements (dust and moisture) and most importantly designed for long-term reliabilty, consistent performance and accuracy. They act as a safety mechanism by automatically shutting off or turning on based on specific pressure levels. Made to be used in diverse applications such as Automotive and or Industrial.
Available for 12V & 24V applications and with 1/8" M NPT Port fitting.

Tolerance: ± 5% of specified pressures.
Torque spec for 1/8” NPT fittings is 10-11 ft. lbs.
Torque spec for 1/4" and 3/8" NPT is 12-15 lb-ft.

Configuration:
165 PSI On, 200 PSI Off, 1/8" NPT, 16 GA wires (20-AMP)

Torques

1/8” NPT

10-11 ft. lbs
