485C-HG | Viair HG-Series Air Compressor

Name: 485C-HG | Viair HG-Series Air Compressor
Brand: Viair
Rating: 5.0 (95 reviews)

The 485C Hyper Grade air compressors are heavy-duty, 200 PSI industrial units designed to fill air tanks and feature a head assembly designed for better heat dissipation. They're equipped with a separate stainless steel braided PTFE-lined leader hose and check valve assembly that protects the compressor against high amperage restarts.

Model:
485C-HG
Brand:
Viair
Code:
48550

SKU:
Availability:

Quantity:



Inquire Add to Basket

12-Volt Air Compressor 200 PSI Air Compressor Air Pump

Specifications

Air Flow Rate

2.00 CFM @ 0 PSI

56.63 LPM @ 0 PSI

Motor Voltage

12-Volt

Motor Type

Permanent Magnetic

Duty Cycle

100% @ 100 PSI

50% @ 200 PSI

Maximum Working Pressure

200 PSI

13.79 BAR

Maximum Air Tank Size

5.0 Gallon

18.93 L

Maximum Current Consumption

23-Amps

Ingress Protection Rating

IP67

Maximum Ambient Temperature

+158 °F

+70 °C

Minimum Ambient Temperature

-40 °F

-40 °C

In Rush Current

98.18-Amps @ 0 PSI

Sound Intensity Level

69.3 dB @ 0 PSI

Dimensions

10.63″L x 4″W x 6.75″H

270 mm （L）x 104.14 mm（W） x 171.5 mm（H）

Net Weight

11.1 lbs

5.04 kg

Features

Thermal Overload Protector
Vibration Isolators
Mounting Hardware
Heavy Duty 3/8″ NPT Check Valve
Stainless Steel Braided
PTFE-Lined Leader Hose
Air Line for Remote Mount Air Filter
Remote Mount Air Filter Assembly
(2) Replacement Air Filter Elements
Installation Instruction

PLEASE NOTE:
Use thread sealant for proper installation. Thread tape is not recommended. Properly sealed, recommended torque for 1/8” is 10 ~ 11 ft. lbs. Recommended torque for 1/4” and 3/8” is 16 ~ 18 ft. lbs. Unless otherwise specified, the gallons mentioned on the webpage are all US gallons.

Performance

12-VOLT COMPRESSOR - Supply Voltage 13.8 Volts

PSI	CFM	A	BAR	LPM	A
0	2.00	11	0	57.0	11
10	1.86	13	1.0	50.0	14
20	1.77	15	2.0	48.0	16
30	1.68	16	3.0	45.0	18
40	1.61	17	4.0	43.0	19
50	1.55	18	5.0	40.0	20
60	1.50	19	6.0	38.0	20
70	1.41	20	7.0	35.0	21
80	1.37	20	8.0	32.0	21
90	1.32	21	9.0	30.0	21
100	1.24	21	10.0	27.0	21
110	1.18	21	11.0	25.0	21
120	1.11	21	12.0	22.0	20
130	1.04	21	13.0	20.0	20
140	0.99	21	14.0	13.0	20
150	0.92	21
160	0.88	21
170	0.80	21
180	0.74	20
190	0.68	20
200	0.63	20

Fill Rates

2.5 GALLON TANK	FILL RATE
0 to 145 PSI	3 minute 06 seconds (± 10 seconds)
110 to 145 PSI	54 seconds (± 05 seconds)
0 to 200 PSI	5 minute 08 seconds (± 15 seconds)
165 to 200 PSI	1 minute 16 seconds (± 05 seconds)
5.0 GALLON TANK	FILL RATE
0 to 145 PSI	6 minut 32 seconds (± 15 seconds)
110 to 145 PSI	1 minute 52 seconds (± 05 seconds)
0 to 200 PSI	10 minute 40 seconds (± 15 seconds)
165 to 200 PSI	2 minute 48 seconds (± 10 seconds)
